• NVIDIA Ada Lovelace Streaming Multiprocessors: Up to 2x performance and power efficiency
• 4th Generation Tensor Cores: Up to 4x performance with DLSS 3 vs. brute-force rendering
• 3rd Generation RT Cores: Up to 2X ray tracing performance
• OC mode: 2640 MHz (OC mode)/ 2610 MHz (Default mode)
• Axial-tech fans scaled up for 23% more airflow
• New patented vapor chamber with milled heatspreader for lower GPU temps
• 3.5-slot design: massive fin array optimized for airflow from the three Axial-tech fans
• Diecast shroud, frame, and backplate add rigidity and are vented to further maximize airflow and heat dissipation
• Digital power control with high-current power stages and 15K capacitors to fuel maximum performance
• Auto-Extreme precision automated manufacturing for higher reliability
• GPU Tweak III software provides intuitive performance tweaking, thermal controls, and system monitoring

SPECIFICATIONS:

Graphic Engine	NVIDIA® GeForce RTX™ 4090
Bus Standard	PCI Express 4.0
OpenGL	OpenGL®4.6
Video Memory	24GB GDDR6X
Engine Clock	OC mode: 2640 MHz Default mode: 2610 MHz (Boost Clock)
CUDA Core	16384
Memory Speed	21 Gbps
Memory Interface	384-bit
Resolution	Digital Max Resolution 7680 x 4320
Interface	Yes x 2 (Native HDMI 2.1a) Yes x 3 (Native DisplayPort 1.4a) HDCP Support Yes (2.3)
Maximum Display Support	4
NVlink/ Crossfire Support	No
Accessories	1 x Collection Card​ 1 x Speedsetup Manual​ 1 x Adapter Cable​ (1 to 4) 1 x ROG White Graphics Card Holder 1 x ROG White Velcro Hook & Loop 1 x Thank you Card 1 x ROG Ring
Software	ASUS GPU Tweak III & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions	357.6 x 149.3 x 70.1mm
Recommended PSU	1000W
Power Connectors	1 x 16-pin
Slot	3.5 Slot
AURA SYNC	ARGB
