Gigabyte Aorus 1200W 80+ Platinum Digital Modular Power Supply
SPECIFICATION
| Model | GP-AP1200PM |
| Type | Intel Form Factor ATX 12V v2.31 |
| PFC | Active PFC (>0.9 typical) |
| Input Voltage | 100-240 Vac (full range) |
| Input Current | 15-7.5A |
| Input Frequency | 60-50 Hz |
| Output Capacity | 1200W |
| Dimension | 150 x 160 x 86mm |
| Fan Type | 140mm Double ball bearing Fan |
| 80 PLUS | Platinum |
| Efficiency | 92% at typical load |
| MTBF | >100,000 hours |
| Protection | OVP/OPP/SCP/UVP/OCP/OTP |
| Power Good Signal | 100-150ms |
| Hold Up Time | >16ms |
| Cable Type | Flat, All black |
| Connectors | ATX/MB 20+4 Pin x 1 : 610mm*1 |
| CPU/EPS 4+4 Pin x 2 : 650mm*2 | |
| PCI-e 6+2 Pin x 10 : 650mm+150mm*4/650mm*2 | |
| SATA x 16 : 650mm+150mm+150mm+150mm*4 | |
| 4 Pin Peripheral x 6+4-Pin floppy x 2 : 600mm+120mm+120mm+150mm*2 |
