• Samsung NVMe SSD powered by newly designed in-house controller
• Up to 7,450 / 6900 MB/s sequential read/write speed
• Power efficient SSD, reliable thermal control, with heatsink

Technical Specifications:

General Feature	Application Client PCs, Game Consoles   Rated Capacity 1,000GB/ 2,000GB/ 4,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)   Form Factor M.2 (2280)   Interface PCIe Gen 4.0 x4, NVMe 2.0   Dimension (Pack: WxHxD) 80 x 24.3 x 8.2 mm (with heatsink)   Weight Max 28.0g Weight   Storage Memory Samsung V-NAND 3-bit MLC   Controller Samsung in-house Controller   Cache Memory Samsung 1GB/ 2GB/ 4GB Low Power DDR4 SDRAM
Special Feature	TRIM Support Supported   S.M.A.R.T Support Supported   GC (Garbage Collection) Auto Garbage Collection Algorithm   Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)   WWN Support Not supported   Device Sleep Mode Support Yes
Performance	Sequential Read Up to 7,450 MB/s * Performance may vary based on system hardware & configuration   Sequential Write Up to 6,900 MB/s * Performance may vary based on system hardware & configuration   Random Read (4KB, QD32) Up to 1,200,000 IOPS * Performance may vary based on system hardware & configuration   Random Write (4KB, QD32) Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration   Random Read (4KB, QD1) Up to 22,000 IOPS * Performance may vary based on system hardware & configuration   Random Write (4KB, QD1) Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
Environment	Average Power Consumption (system level) *Average: 5.4 W*Maximum: 7.8 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration   Power consumption (Idle) Max. 50 mW * Actual power consumption may vary depending on system hardware & configuration   Allowable Voltage 3.3 V ± 5 % Allowable voltage   Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)   Operating Temperature 0 - 70 ℃ Operating Temperature   Shock 1,500 G & 0.5 ms (Half sine)
Software	Management SW Magician Software for SSD management
